Mean Well PLD-40 Series LED Driver  40W 350mA – 1750mA

Mean Well PLD-40 Series LED Driver 40W 350mA – 1750mA

Mean Well PLM-12 Series LED Driver 12W 350mA – 1050mA

Mean Well PLM-12 Series LED Driver 12W 350mA – 1050mA

Mean Well PLD-60 Series LED Driver 60W 500mA – 2400mA

180~295VAC input

Built-in active PFC function

Protections: Short circuit/ Over temperature

Other features:

  • Constant current design
  • Fully isolated plastic case
  • IP30 design
  • Class 2 power unit/ Pass LPS
  • Isolation class II, no F.G.
  • 100% full burn-in test
  • Cooling by free air convection
  • 3 years warranty
£24.17
Availability: In stock
Part No
PLD-60-S

180~295VAC input

Built-in active PFC function

Protections: Short circuit/ Over temperature

Other features:

  • Constant current design
  • Fully isolated plastic case
  • IP30 design
  • Class 2 power unit/ Pass LPS
  • Isolation class II, no F.G.
  • 100% full burn-in test
  • Cooling by free air convection
  • 3 years warranty
More Information
Manufacturer Mean Well
Output Wattage (W) 60
Output Current Choose Option
Dimmable (Type) No
Dimensions 128x 60x 31.5
EMC Standards Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A
Input Voltage 180~295VAC
Safety Standards UL8750, ENEC EN61347-1, EN61347-2-13 independent, IP30 approved
Output Voltage Options Single
Working Temperature -30~+50°C
PDF Datasheet PLD-60-spec_8.pdf
