Mean Well LPH-18 Series Double Insulated Mains Input LED Driver 18W - 20W 12V – 36V

Available to Backorder - Expected in 7-10 Days
Part No
LPH-18-TFS

Constant Voltage

Fully encapsulated with IP67 level

Protections: Short circuit/ Overload/ Over voltage/ Over temperature

Other features:

  • 180~264VAC
  • Class 2 power unit
  • Isolation class II, no F.G.
  • Cooling by free air convection
  • Pass LPS
  • 100% full load burn-in test
  • Low cost, High reliability
  • 2 years warranty
More Information
BrandMean Well
Output Wattage (W)18
Dimmable (Type)No
Dimensions140 x 30 x 20 (LxWxH) Mm
EMC StandardsEN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage180~264VAC
Safety StandardsTUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13
Output Voltage OptionsSingle
Working Temperature-20~+70°C
PDF DatasheetLPH-18TF_Series.pdf
Item ReturnsThis item can be returned

Details

Constant Voltage

Fully encapsulated with IP67 level

Protections: Short circuit/ Overload/ Over voltage/ Over temperature

Other features:

  • 180~264VAC
  • Class 2 power unit
  • Isolation class II, no F.G.
  • Cooling by free air convection
  • Pass LPS
  • 100% full load burn-in test
  • Low cost, High reliability
  • 2 years warranty

More Information

More Information
BrandMean Well
Output Wattage (W)18
Dimmable (Type)No
Dimensions140 x 30 x 20 (LxWxH) Mm
EMC StandardsEN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage180~264VAC
Safety StandardsTUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13
Output Voltage OptionsSingle
Working Temperature-20~+70°C
PDF DatasheetLPH-18TF_Series.pdf
Item ReturnsThis item can be returned
