Mean Well LED Driver PLM-40-350 37W 350mA
£22.80
£19.00
Out of stock
Part No
PLM-40-350
Constant current design
Three-step analogue dimming
Protections: Short circuit/ Over temperature
Other features:
- Universal AC input (up to 295VAC)/ Full range
- Built-in active PFC function
- No load power consumption <0.5W
- Cooling by free air convection
- IP30 design
- Fully isolated plastic case
- Class II power unit, no FG
- 100% full load burn-in test
- High reliability, low cost
- Suitable for indoor LED lighting applications
- 2 years warranty
| Brand | Mean Well |
|---|---|
| Output Wattage (W) | 37 |
| Output Current (mA) | 350mA |
| Dimmable (Type) | No |
| Output Voltage Range (V) | 53~105 |
| Dimensions | 175x 42x 24 |
| EMC Standards | Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11; EN61547, light industry level (surge 2KV), criteria B |
| Input Voltage | 90~295VAC 127~417VDC |
| Safety Standards | UL8750, CSA C22.2 No.250. 13-12 (for PLM-40-1400/ 1750), ENEC EN61347-1, EN61347-2-13, EN61347-2-13, EN62384, IP30 approved |
| Output Voltage Options | Single |
| Working Temperature | -30~+60°C | PDF Datasheet | PLM-40-spec_3.pdf |
