Mean Well LED Driver LPV-100-24TF 100W 24V
Double insulated mains input
Constant Voltage
Protections: Short circuit/ Overload/ Over voltage
Other features:
- Universal AC input / Full Range
- Fully encapsulated with IP67 level
- Isolation class II, no F.G.
- Withstand 300VAC surge input for 5 seconds
- Cooling by free air convection
- 100% full load burn-in test
- Low cost, High reliability
- 2 years warranty
More InformationBrand | Mean Well |
---|
Output Wattage (W) | 100 |
---|
Dimensions | 190 x 52 x 37 |
---|
EMC Standards | EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 |
---|
Input Voltage | 90~264VAC |
---|
Safety Standards | Design refer to TUV EN60950-1, EN61347-2-13 |
---|
Output Voltage Options | Single |
---|
Working Temperature | -30°C~+70°C |
---|
PDF Datasheet | LPV-100TF-spec_4.pdf |
---|
Return period | 14 days |
---|
Frequently Bought Together
Details
Double insulated mains input
Constant Voltage
Protections: Short circuit/ Overload/ Over voltage
Other features:
- Universal AC input / Full Range
- Fully encapsulated with IP67 level
- Isolation class II, no F.G.
- Withstand 300VAC surge input for 5 seconds
- Cooling by free air convection
- 100% full load burn-in test
- Low cost, High reliability
- 2 years warranty
More Information
More InformationBrand | Mean Well |
---|
Output Wattage (W) | 100 |
---|
Dimensions | 190 x 52 x 37 |
---|
EMC Standards | EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 |
---|
Input Voltage | 90~264VAC |
---|
Safety Standards | Design refer to TUV EN60950-1, EN61347-2-13 |
---|
Output Voltage Options | Single |
---|
Working Temperature | -30°C~+70°C |
---|
PDF Datasheet | LPV-100TF-spec_4.pdf |
---|
Return period | 14 days |
---|
