Mean Well LED Driver LPH-18-24 18W 24V

Name: Mean Well LED Driver LPH-18-24 18W 24V
SKU: LPH-18-24
Price: 10.740001 GBP
Availability: OutOfStock

£10.74 £8.95

Out of stock

Part No

LPH-18-24

Constant Voltage

Fully encapsulated with IP67 level

Protections: Short circuit/ Overload/ Over voltage/ Over temperature

Other features:

More Information
Brand	Mean Well
Output Wattage (W)	18
Output Voltage	24V
Dimmable (Type)	No
DC Output Adjustment	N/A
Dimensions	140 x 30 x 20
EMC Standards	EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage	180~264VAC
Safety Standards	TUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13
Output Voltage Options	Single
Working Temperature	-10~+60°C
PDF Datasheet	LPH-18-SPEC.PDF

Frequently Bought Together

Details

Constant Voltage

Fully encapsulated with IP67 level

Protections: Short circuit/ Overload/ Over voltage/ Over temperature

Other features:

More Information
Brand	Mean Well
Output Wattage (W)	18
Output Voltage	24V
Dimmable (Type)	No
DC Output Adjustment	N/A
Dimensions	140 x 30 x 20
EMC Standards	EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage	180~264VAC
Safety Standards	TUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13
Output Voltage Options	Single
Working Temperature	-10~+60°C
PDF Datasheet	LPH-18-SPEC.PDF

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account
