Mean Well LED Driver LPC-60-1050 50W 1050mA

£24.95 £20.79
In stock
Part No
LPC-60-1050

Constant Current

Fully encapsulated with IP67 level

Protections: Short circuit/ Overload/ Over voltage

Other features:

  • Universal AC input/ Full range
  • Withstand 300VAC surge input for 5 seconds
  • Isolation class II, no F.G.
  • Cooling by free air convection
  • Class 2 power unit
  • Pass LPS
  • 100% full load burn-in test
  • Low cost, high reliability
  • 2 years warranty
More Information
BrandMean Well
Output Wattage (W)50
Output Current (mA)1050mA
Dimmable (Type)No
Output Voltage Range (V)9~48
Dimensions162.5 x 42.5 x 32
EMC StandardsEN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage90~264VAC
Safety StandardsUL1310, UL879 approved; Design refer to TUV EN60950-1, EN61347-2-13
Output Voltage OptionsSingle
Working Temperature-40~+70°C (refer to output derating curve)
PDF DatasheetLPC-60-spec.pdf
Return period14 days

Details

Constant Current

Fully encapsulated with IP67 level

Protections: Short circuit/ Overload/ Over voltage

Other features:

  • Universal AC input/ Full range
  • Withstand 300VAC surge input for 5 seconds
  • Isolation class II, no F.G.
  • Cooling by free air convection
  • Class 2 power unit
  • Pass LPS
  • 100% full load burn-in test
  • Low cost, high reliability
  • 2 years warranty

More Information

More Information
BrandMean Well
Output Wattage (W)50
Output Current (mA)1050mA
Dimmable (Type)No
Output Voltage Range (V)9~48
Dimensions162.5 x 42.5 x 32
EMC StandardsEN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage90~264VAC
Safety StandardsUL1310, UL879 approved; Design refer to TUV EN60950-1, EN61347-2-13
Output Voltage OptionsSingle
Working Temperature-40~+70°C (refer to output derating curve)
PDF DatasheetLPC-60-spec.pdf
Return period14 days
