Mean Well LED Driver HLG-100H-24A 96W 24V

£60.11 £50.09
Available to Backorder - Expected in 7-10 Days
Part No
HLG-100H-24A

IP65 design for indoor or outdoor installations

Built-in active PFC, PF>0.9 for 60% of load or higher

5 years warranty

Protections: Short circuit / Over current / Over voltage / Over temperature

Other features:

  • Universal AC input (up to 305VAC) / Full range
  • High efficiency up to 94%
  • Output current adjustable through output cable or internal potentiometer
  • Cooling by free air convection
  • Suitable for dry, damp and wet location
  • Suitable for LED lighting and street lighting applications
  • Meet 4KV surge immunity level (IEC61000-4-5)
  • Class 2 power unit
  • Output and C.C level can be adjusted through internal potentiometer
More Information
BrandMean Well
Output Wattage (W)96
Output Voltage24V
Dimmable (Type)No
DC Output Adjustment22 ~ 27V
Dimensions220x 68x 38.8
EMC StandardsEN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024
Input Voltage90~305VAC, 127~431VDC
Safety StandardsUL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-2-13 approved; Design refer to UL60950-1, EN60950-1
Output Voltage OptionsSingle
Working Temperature-40~+70°C (refer to output derating curve)
PDF DatasheetHLG-100H-spec_8.pdf
Return period14 days

Details

IP65 design for indoor or outdoor installations

Built-in active PFC, PF>0.9 for 60% of load or higher

5 years warranty

Protections: Short circuit / Over current / Over voltage / Over temperature

Other features:

  • Universal AC input (up to 305VAC) / Full range
  • High efficiency up to 94%
  • Output current adjustable through output cable or internal potentiometer
  • Cooling by free air convection
  • Suitable for dry, damp and wet location
  • Suitable for LED lighting and street lighting applications
  • Meet 4KV surge immunity level (IEC61000-4-5)
  • Class 2 power unit
  • Output and C.C level can be adjusted through internal potentiometer

More Information

More Information
BrandMean Well
Output Wattage (W)96
Output Voltage24V
Dimmable (Type)No
DC Output Adjustment22 ~ 27V
Dimensions220x 68x 38.8
EMC StandardsEN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024
Input Voltage90~305VAC, 127~431VDC
Safety StandardsUL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-2-13 approved; Design refer to UL60950-1, EN60950-1
Output Voltage OptionsSingle
Working Temperature-40~+70°C (refer to output derating curve)
PDF DatasheetHLG-100H-spec_8.pdf
Return period14 days
