Mean Well LED Driver APV-25-12  25W 12V

Mean Well LED Driver APV-25-12 25W 12V

Mean Well LED Driver APV-25-24 25W 24V

Mean Well LED Driver APV-25-24 25W 24V

Mean Well LED Driver APV-25-15 25W 15V

Constant Voltage

Fully isolated plastic case

Protections: Short circuit/ Overload/ Over voltage

Other features:

  • Universal AC input / Full Range
  • Small and compact size
  • Withstand 300VAC surge input for 5 seconds
  • Isolation class II, no FG
  • Cooling by free air convection
  • Pass LPS
  • 100% full load burn-in test
  • Low cost, High reliability
  • 2 years warranty
£14.41
Availability: In stock
Part No
APV-25-15
More Information
Manufacturer Mean Well
Output Wattage (W) 25
Output Voltage 15V
Dimmable (Type) No
DC Output Adjustment N/A
Dimensions 84x 57x 29.5
EMC Standards EN55022, EN61000-3-2 Class A, EN610003-3, EN55024, EN61000-4-2, 3, 4, 5, 6, 8, 11; light industry level (surge 2KV), criteria A
Input Voltage 90~264VAC, 127VDC~370VDC
Safety Standards Design refer to EN60950-1, UL8750
Output Voltage Options Single
Working Temperature -30°C~+70°C (Refer to "Derating Curve")
PDF Datasheet APV-25-spec_3.pdf

Constant Voltage

Fully isolated plastic case

Protections: Short circuit/ Overload/ Over voltage

Other features:

  • Universal AC input / Full Range
  • Small and compact size
  • Withstand 300VAC surge input for 5 seconds
  • Isolation class II, no FG
  • Cooling by free air convection
  • Pass LPS
  • 100% full load burn-in test
  • Low cost, High reliability
  • 2 years warranty
