Mean Well LED Driver APC-16-350 16W 350mA

£7.51
In stock
Part No
APC-16-350

Constant Current

Fully isolated plastic case

Protections: Short circuit/ Over voltage

Other features:

  • Universal AC input / Full Range
  • Small and compact size
  • Isolation class II, no FG
  • Cooling by free air convection
  • Pass LPS
  • 100% full load burn-in test
  • Low cost, High reliability
  • 2 years warranty
More Information
Manufacturer Mean Well
Output Wattage (W) 16
Output Current 350mA
Dimmable (Type) No
Output Voltage Range (V) 12~48
Dimensions 77 x 40 x 29
EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547
Input Voltage 90~264VAC; 127~370VDC
Safety Standards Design refer to TUV EN60950-1, EN61347-2-13, UL8750
Output Voltage Options Single
Working Temperature -30°C~+70°C (Refer to "Derating Curve")
PDF Datasheet APC-16-spec.pdf

Constant Current

Fully isolated plastic case

Protections: Short circuit/ Over voltage

Other features:

  • Universal AC input / Full Range
  • Small and compact size
  • Isolation class II, no FG
  • Cooling by free air convection
  • Pass LPS
  • 100% full load burn-in test
  • Low cost, High reliability
  • 2 years warranty
