ECOPAC LED DRIVER ELED-60-12V SERIES 60W 12V

ECOPAC LED DRIVER ELED-60-12V SERIES 60W 12V

ECOPAC ELED-60-V SERIES LED DRIVER 60W 12-24V

Ecopac ELED-60-V Series Constant Voltage LED Driver 60W 12-24V

ECOPAC LED DRIVER ELED-60-24V SERIES 60W 24V

Three in one dimming function (0/1-10Vdc or PWM signal or resistance)

IP66 design for indoor or outdoor installation

Protections: Short circuit/ Over Current/ Over Temperature / Over Loading

Other features:

  • Universal AC input/ Full range 100-265VAC
  • Built-in active PFC function
  • Dimming range: 0-100%
  • 3 years warranty
£51.84
Availability: In stock
Part No
ELED-60-24V

Three in one dimming function (0/1-10Vdc or PWM signal or resistance)

IP66 design for indoor or outdoor installation

Protections: Short circuit/ Over Current/ Over Temperature / Over Loading

Other features:

  • Universal AC input/ Full range 100-265VAC
  • Built-in active PFC function
  • Dimming range: 0-100%
  • 3 years warranty
More Information
Manufacturer Ecopac Power
Output Wattage (W) 60
Output Voltage 24V
Dimmable (Type) 0-10V, PCW Signal & Resistance
Dimensions 200x 70x 46
EMC Standards Compliance to EN55015, EN61000-3-2 (>60% load) Compliance to EN61000-4-2,3,4,5,6,11, EN61547, light industry level (surge 4KV) Criteria A
Input Voltage 100-265VAC
Safety Standards EN61347-1, EN61347-2-13
Output Voltage Options Single
Working Temperature -40~+60°C
PDF Datasheet ELED-60-V.pdf
