Ecopac LED Driver ELED-20-24V 20w 24V

Be the first to review this product
£28.32 £23.60
Out of stock
Part No
ELED-20-24V

Universal AC input/full range 100-265VAC
Built-in active PFC function
High efficiency up to 86%
Protections: Short circuit/Over current/ Over loading
Cooling by free air convection
Fully isolated plastic case with terminals IP20
Class 2 Power unit
Three in one dimming function (0/1-10Vdc or PWM signal or resistance)
Dimming range: 0-100%
Suitable for LED lighting and moving sign applications
Compliance to worldwide safety regulations for lighting

More Information
Brand Ecopac Power
Output Wattage (W) 20
Output Voltage 24V
Dimmable (Type) 0-10V, Potentiometer, 10V PWM dimmable
Dimensions 140x 45x 27mm
EMC Standards Compliance to EN55015, EN61000-3-2 (>60%load), Compliance to EN61000-4-2,3,4,5,6,11, EN61547, light industry level (surge 4KV) Criteria A
Input Voltage 100-265Vac
Safety Standards EN61347-1 EN61347-2-13
Output Voltage Options Single
Working Temperature -40-+60°C
PDF Datasheet ELED-20-V_Seires_1.pdf
