Ecopac ELED-75-24D DALI Dimmable LED Driver 75W 24V

Special Price £64.73 Regular Price £69.60
In stock
Part No
ELED-75-24D

The Ecopac ELED-75-24D DALI Dimmable LED Driver is 75W 24VDC output.

Constant Voltage  / PWM Output Design

Dali & Push Dimmable

Protections: Short circuit/ Over Voltage/ Over Temperature

Other features:

  • Dimming range from 0.1% to 100%
  • Input Range 200-265VAC
  • Output 24VDC
  • Built-in PFC function
  • IP20design for indoor or outdoor installations
  • 87% efficiency
  • 3 years warranty
More Information
Brand Ecopac Power
Output Wattage (W) 75
Output Voltage 24V
Dimmable (Type) DALI, Push Dimming
DC Output Adjustment No
Dimensions 355 x 215 x 215 mm
EMC Standards Compliance to EN55015, EN61000-3-2, EN61000-3-3 (?60% load), EN61000-4-2,3,4,5,6,11, EN61547
Input Voltage 100-265VAC
Safety Standards EN61347-1, EN61347-2-13, EN62493, IP20
Output Voltage Options Single
Working Temperature -40 ~ +60°C
PDF Datasheet ELED-75-D.pdf
Frequently Bought Together
  • Total price

The Ecopac ELED-75-24D DALI Dimmable LED Driver is 75W 24VDC output.

Constant Voltage  / PWM Output Design

Dali & Push Dimmable

Protections: Short circuit/ Over Voltage/ Over Temperature

Other features:

  • Dimming range from 0.1% to 100%
  • Input Range 200-265VAC
  • Output 24VDC
  • Built-in PFC function
  • IP20design for indoor or outdoor installations
  • 87% efficiency
  • 3 years warranty
